PRECISIO-4
PRECISIO 4 - Electric
PRECISIO 4 - Electric LPG pump Auto filling & with Auto Switch-off - Fully electrical FILLING SYSTEM
The BEST of the best LPG PUMP in SA
Specifications:
• Ex approved - for transferring from 3kg, 5kg, 6kg, 9g, 14kg, 19kg & 48kg via electronic LPG filling
• Designed with electronic valve
• Self contained, complete with hoses & filling ADAPTORS
• Platform dimensions: 40cm x 50cm;
• Power: Rechargeable battery - up to 40hrs continues operation
• Equipped with spare battery and charger
• Dimensions: 50(W) x 70(L) x 55(H)
Optional: 5mm chequered top plate
Pump Features:
• Filling time: 9kg/+-6min
• Complete Semi-Automatic Pumping
• EX rated motor
• Auto-Shut off: YES
Technical Facts of pump - High-pressure transfer 2-Diaphragm piston pump:
• Type: 2-Diaphragm (with Vito membrane) Pump
• Flow Rate: ~30 Litres per minute
• Max Pressure: 40 Bar
• Power Requirement: 2.2 kW (2.9 HP)
• Operating Speed: 540 RPM
• Oil Type: 20W50
• Oil Capacity: 0.5 L
Technical Facts of pump - 220V:
• Voltage: 220V
• Amperage: 6.20 / 5.45A
• Kilowatt: 0.55kW / 0.75kW
• Synchronous Speed: 1500 rpm (Rated speed: 1470 rpm)
• Frame size: Ex61G
• Insulation Class: H / B
• Ex Marking: Ex db IIA T3 Gb
• IA Number: MASC S/19-2047X
Pump features:
• High-Pressure Pump Head: The central mechanism features
a mechanical plunger pump assembly with an integrated oil reservoir bottle (the vertical clear container with a yellow cap
showing amber-colored mechanical oil).
• Electric Motor: Partially visible on the far left, powering the pump assembly via a direct coupling or drive belt.
• Fluid Connections: Fitted with dual red-handled shut-off ball valves for controlling intake/output flow and a coiled heavyduty black high-pressure hose.
• Base Frame: Mounted on a sturdy metal skid
Selectable to your needs if scale be placed on top or on the floor. |
|
|
|
